EC-PM-80320 Service Manual
- 12 -
20 37.61
25 30.00
30 24.11
35 19.51
40 15.89
45 13.03
50 10.75
55 8.92
60 7.45
65 6.25
70 5.27
75 4.47
80 3.80
85 3.25
90 2.79
95 2.41
100 2.09
4.2.2 Paper Sensor
EC-PM-80320 printer has two sensors (the light glint type) inside which are used to check whether
there is paper, and also establishes an external electric circuit to check the output of sensor. One
sensor is set under the print head, and the printer will stop printing when lack of paper is detected by
this sensor, and it is valid by default. The other sensor is located at the side of paper holder, and the
printer will stop printing when the print paper is about to use up detected by this sensor, and it is
invalid by default. The function of stop printing by the two sensors is valid or not can be set by
control program. The thermal head may be damaged and the life-span will be seriously infected due
to printing on the condition of paper out.
Table4-4 and Table4-5 is paper sensor’s parameters in common use.
Sort Sign Maximum Rating
Positive Electricity IF 50mA
Reverse Electricity VR 5V
LED（Input）
Allowed Power P 75mW
Voltage from collected port to Transmitted port VCEO 20V
Voltage from Transmitted port to collected port VECO 5V
Collected Electricity IC 20mA
Light Echo (output)
Collected Waste PC 70mW
Working Temperature Topr -20t o +80℃
Deposited Temperature Tstg -30 to 100℃
Sort Sign Condition Min. Standard Max.
LED（Input） Positive Electricity VF IF=10mA 1.0V 1.2V 1.6V
Table4-3 Corresponding value of thermal resistance
Table 4-4 The maximum Rating of paper sensor at 25℃.
