EC-PM-80320 Service Manual
- 1 -
Chapter 1 Printer Introduction
1.1 Explanation and application
EC-PM-80320 printer is a kind of high-speed mini thermal printer with high quality, high reliability
and low noise. It does not need ribbon cartridge and can be operated easily. EC-PM-80320 printer
can be widely used in ECR, PC-POS and BANK POS for printing various kinds of receipts.
1.2 Product type
In order to fulfill different requirements and operating circumstance, manufacturer develops
EC-PM-80320 series products which are high-speed thermal mini-printers.
According to different data ports (interfaces), EC-PM-80320 series can be classified into different
models: EC-PM-80320, EC-PM-80320U, EC-PM-80320US, EC-PM-80320UE, EC-PM-80320UB
and EC-PM-80320UW.
EC-PM-80320 series printer is equipped with an auto cutter which has two options for the consumer
to select: partial cutter can only cut the paper with one point left while full cutter cuts the paper fully.
Interface:
EC-PM-80320 series products are configured with a cash drawer interface, you can choose one of
the following data interfaces when purchasing this product:
Model Interface
EC-PM-80320 Parallel interface
EC-PM-80320U USB interface
EC-PM-80320US USB interface + Serial interface
EC-PM-80320UE USB interface + Ethernet interface
EC-PM-80320UB USB interface + Bluetooth
EC-PM-80320UW USB interface + Wi-Fi
1.3 Characteristic
(a) Super high-speed printing
The maximal speed can reach to 220 mm/s.
(b) Installing paper easily
The platen roller part which can be opened make you install paper easily.
(c) High Resolution
Thermal print head with high density (8 dots/mm) can provide clear printing result.
(d) Long life-span
Be able to print paper with the length of 100km.
(e) Low noise
Thermal printing mode ensures low noise.
(f) Cleaning thermal print head easily
The platen roller part which can be removed make you clean the thermal print head easily.
(g) Preventing static
The frame ground connecting to the outside metal parts can reduce the faradic current
radiation to the minimum.
