EC Line EC-PM-80320 User Manual

EC-PM-80320 Service Manual
- 26 -
A.2 Parts List for EC-PM-80320
NO. Parts name SAP Qty Note
1 Screw PM3X6 100000000770 7
2 Mechanism assembly 200000000508 1
3 Label 2 510000010892 1
4 Printer connected flat cable 100000001782 1
5 Mechanism frame 100000001009 1
6 Screw PM3X4 100000000929 13
7 Mechanism support 100000001008 1
8 Screw M3X5X7 100000000966 6
Top cover (black) 200000026046 1
9
Top cover (white) 200000025709 1
10 Caution label 510000009652 1
510000010091 1 White
11 Control panel label
510000009660 1 Gray
Upper cover (black) 200000026048 1
12
Upper cover (white) 200000025716 1
13 Trademark label 510000000081 1
14 Label1 510000000094
Front cover (black) 200000026047 1
15
Front cover (white) 200000025714 1
16 High temperature caution label 510000000078 1
17 Cutter slider 100000052129 1
18 Manual cutter 100000001005 1
Front knob（Black）
200000026044 1
19
Front knob（White）
200000025702 1
20 Screw PA2.6X5 100000000946 2
21 Power switch 100000000990 1
22 Baseplate 100000001006 1
23 Main PCBA 200000026549 1
24 Screw PWM3X6 100000000310 9
25 Baseplate cover 100000001007 1
Bottom housing (Black) 200000026049 1
26
Bottom housing (White) 200000025718 1
DIP switch cover (Black) 200000026045 1
27
DIP switch cover (White) 200000025703 1
28 Screw HPB2.5X4 100000001042 1
29 Round rubber cushion 100000000944 4
30 Interface caution label 510000009657 1
Joint pin (Black) 200000026043 1
31
Joint pin (White) 200000025701 1
32 Screw HPB3*8 100000000546 2
33
USB + Ethernet interface assembly 200000028151 1
