B.2 Parts List for MPM-80T Drawing
NO. Parts name SAP Qty Note
1 Paper feed motor 100000051980 1
2 Screw BM2X2 100000001038 2
3 Knob support plate 100000001021 1
4 Screw PM3x4 100000000929 7
5 Paper feed gear A 200000025707 1
6 E-ring Φ1.5 100000000940 2
7 Paper feed gear B 200000025706 1
8 E-ring Φ2.0 100000000964 3
9 Baseplate assembly 100000001018 1
10 Support shaft 100000001030 1
11 Screw PM3x6 100000000770 4
12 Front knob 200000026044 1
13 Knob 200000025711 1
14 Screw HPM1.6x4.5 100000001039 1
15 Microswitch 100000001036 1
16 Support spring 100000001031 3
17 PH plate 100000001020 1
18 PH holding plate 100000001019 1
19 3M Tape 100000001034 1
20 Thermal print head 100000000981 1
21 Rolling ring 2 100000052969 1
22 Platen 100000052970 1
23 Cutter bracket 100000001024 1
24 Stationary blade shim L 100000054702 1
25 Stationary blade shim R 100000054701 1
26 Screw PM2.5x4 100000000925 2
27 Patch 510000010391 1
28 Paper guide film 510000010390 1
29 Automatic cutter (Rotary) 100000047521 1
30 Screw PM2x3 510000010319 2
31 Worm protecting film 100000054810 1
32 Elastic washer 100000049787 2
33 Paper clog film_Upper 100000054805 1
34 Spring 100000054436 1
35 Screw BM2x2 100000001038 2
36 Automatic cutter (stationary) 100000047521 1
37 Paper clog film_Bottom 100000054806 1
38 Cutter support 100000053274 1
39 Paper feed gear C 200000025708 1
40 Rolling ring 100000052571 1
41 Paper guide 200000025710 1
