33
1) Press 【F2】 to set paper speed. Four kinds of speed are available for selection: 6.25mm/s,
12.5mm/s, 25mm/s and 50 mm/s;
2) Press 【F3】 to set sensitivity . Four kinds of sensitivity are available for selection:
2.5mm/mV, 5mm/mV, 10mm/mV and 20mm/mV;
3) When waveforms become stable, press 【Start/Stop】for recording, and the record length is
0~60 seconds, the ECG rhythm lead waveform with rhythm analysis will printed out. If
needing to pause or stop the print, just press 【START/STOP】button.
5.3.3 Auto Mode
Under Auto Mode, select 6 automatic display formats through “display setup” screen:
3CH×4, 3 CH×4+1R, 3 CH×4+3R, 6 CH×2, 6 CH×2+1R and 12 CH×1.
z 3 CH×4 3rows ×4 columns
z 3 CH×4+1R 3rows ×4 columns+ 1 rhythm lead
z 3 CH×4+3R 3 rows×4 columns+ 3 rhythm leads
z 6 CH×2 6 rows×2 columns
z 6 CH×2+1R 6 rows×2 columns+1 rhythm lead
z 12 CH×1 12 rows×1 column
3×4format
1) Press 【F2】to set paper speed. Four kinds of speed for selection: 6.25mm/s, 12.5mm/s,
25mm/s and 50 mm/s;
2) Press 【F3】 to set sensitivity. Four kinds sensitivity of for selection: 2.5mm/mV, 5mm/mV,
10mm/mV and 20mm/mV;
