EC-PM-80320 User's Manual
- 17 -
2”. Double click it and the window of “Wireless Network Connection” pops up, select and double
click the corresponding printer Wi-Fi name. The printer Wi-Fi default name is composed of “the
printer model+6 numbers and letters” (as shown in Figure 1)
(2) Connecting to the equipment in Android
Take the mobile phone of Android 4.4 as an example to show how to connect the printer with the
equipment in Android.
1. Turn on the printer and make sure the printer is in normal working condition. Start the operation
30 seconds after the printer is on.
2. Click “Settings” and the interface pops up. Select the “WLAN” function to “ON”, then click the
printer Wi-Fi searched by the mobile phone to connect. The printer Wi-Fi default name is
composed of “the printer model+6 numbers and letters” (as shown in Figure 2).
Figure 1
Double click it
The printer Wi-Fi of this
example.
