Mounting instruction
Names of lead wires and destinations (refer to Page 92)
No. Name Wire color Destination
1 ACC Red Connect where the power comes on
when the ignition is in the ACC
position.
2 B+ Yellow Connect where the power is constantly
available, regardless of the ignition
switch's position.
3 Ground Black Connect where good body grounding
is available.
4
Antenna power supply
Blue Connect to the automatic-antenna
control terminal of the vehicle.
5
Lamp power supply
Orange/White
Connect to where power comes on
when the headlights are turned on.
6
Control power supply
Blue/White
Connect to the control terminal for
the external amplifier, etc.
7 E-LAN terminal Connect to the E-LAN terminal of the
CD changer, DSP, etc.
8 & 9
Line-in/out terminals Connect to the RCA input connectors
of an external amplifier,or to the RCA
output connectors of a DSP or EQ.
10
Line-out terminals
(
Nonfader)
Connect to the RCA input connectors
of a DSP or EQ, or the RCA connectors
of a woofer amplifier.
11 Speaker terminals Connect them to their respective
speakers.
12
Cellular phone mute
Pink Connect to the ground output terminal
on a mobile phone.
13 Digital out terminal Connect to digital input terminal of the
Eclipse Commander module.
14
Eclipse Commander terminal
Connect to the Eclipse Commander
module.
15 Line in terminal Connect to the mini plug (φ3.5)
output connector of Portable unit
(MP3 player, MD player, etc).
O Note O
To prevent unconnected leads from shorting out, insulate them
by wrapping their tips with electrical tape. Similarly, insulate the
ends of connected leads.
If an external amplifier is to be connected to the receiver, be
sure to ground its outside housing to the vehicle body (a metal
part).
