TO POWER ANTENNA RELAY (Supply)
TO HEADLIGHT SWITCH (Illumination)
TO TURN-ON LEAD OF EACH UNIT (Supply)
TO ACC (Power Supply)
1
TO BATTERY+12V
(Permanent Supply)
2
TO GROUND
Pink
Purple/Black
Black
Purple
Green/Black
Blue/White
Orange/White
Blue
Red
Yellow
Green
Gray/Black
White/Black
White
13P
13P
13P
16P
CD5423
2P
CH3083
CH3083
13P
2P
ANTENNA PLUG
Gray
3
4
5
6
CELLULAR PHONE
(For mute)
12
DIGITAL OUT
13
CD5423+ CH3083 + CH3083 + Power Amplifier
3)
INTERCONNECTING CABLE
12
INSULATE EACH
WIRE WITH TAPE
INSULATE EACH
WIRE WITH TAPE
(A)
(B)
15
Note: 1. The switch on the back side of CD changer ( A ) must be set to the "L" position.
2. The switch on the back side of CD changer ( B ) must be set to the "H" position.
TO SIGNAL INPUT
OF AUXILIARY
POWER AMPLIFIER
To Portable unit
(MP3 Player, MD Player, etc)
NON-FADER
10
14
