Eclipse CD8051 - Page 83

83
How to operate the receiver with an optional DSP/EQ unit or Digital Sound Processor connected
5. Hold down a button, [1] to [6], for more than two seconds
to preset a value.
The preset value is overwritten by the value set using
the above steps.
When the preset value is changed, the display shows as
follows:
USER
1~6 (Preset ch No.)
6.
Push
the [FUNC] button .
This cancels the adjustment mode. The selected value
will now take effect.
 Selecting an equalizer mode from
memory
Press a preset button to select the equalizer mode set in
memory for the button.
The buttons that set equalizer modes in memory are called
preset buttons.
1.
After pressing the [FUNC] button, hold button [2]
down for more than one second.
2. Press the button, [1] to [6] for less than two
seconds.
3. Press the [FUNC] button.
The selected equalizer mode will now take effect, and
the EQ adjustment mode will be canceled.
Easy-operation is used in normal audio control mode.
Buttons [1] to [6]
[FUNC] button
