Technical service manual ecoGEO
33
EN
3. Technical specifications ecoGEO B | ecoGEO C
3.1. Component location
No.
Description
No.
Description
1
Production outlet
28
Passive cooling brine valve
2
Production return
29
Compressor suction temp. probe
3
Brine outlet
30
Compressor discharge temp. probe
4
Brine inlet
31
Brine outlet temp. probe
5
DHW inter-accumulator outlet
32
Brine inlet temp. probe
6
DHW inter-accumulator inlet
33
Production outlet temp. probe
7
Evaporator (direct cycle)
34
Production inlet temp. probe
8
Condenser (direct cycle)
35
Suction pressure transducer
9
HTR system exchanger
36
Discharge pressure transducer
10
Passive cooling / defrosting exchanger
37
Brine pressure transducer
11
Compressor
38
Production pressure transducer
12
Electronic expansion valve
39
Suction mini-pressure switch
13
Filter dryer
40
Discharge mini-pressure switch
14
Cycle inversion valve
41
Service outlet
15
Production circulator pump
42
Cooling outlet inverter
16
Brine circulator pump
43
Cooling inlet inverter
17
HTR circulator pump
44
Outlet resistor
18
Brine expansion vessel
45
Safety thermostat
19
Production expansion vessel
46
Electrical panel
20
Brine safety valve
47
Tap water inlet
21
Production safety valve
48
DHW outlet
22
HTR system retention valve
49
DHW Recirculation
23
Brine drain valve
50
DHW storage tank
24
Production discharge valve
51
DHW coil
25
HTR system discharge valve
52
Manual trap
26
DHW valve
53
Storage tank drain valve
27
Passive cooling production valve
54
DHW temperature probe
