ECOFOREST ecogeo basic - Electrical Connection Tables

Technical service manual ecoGEO
61
EN
4.3. Electrical connection tables
ANALOGUE INPUTS
CONNECTIONS
DESCRIPTION
Connection terminal
Controller terminal
Type
Signal
Block I / AI1
pCO5+ / J2 / U1
NTC 10K 25°C
Brine outlet temperature
Block I / AI2
pCO5+ / J2 / U2
NTC 10K 25°C
Brine inlet temperature
Block I / AI3
pCO5+ / J2 / U3
Radiometer 0-5Vdc
Brine circuit pressure
Block I / AI4
pCO5+ / J3 / U4
NTC 10K 25°C
Production outlet temperature
Block I / AI5
pCO5+ / J3 / U5
NTC 10K 25°C
Production inlet temperature
Block I / AI6
pCO5+ / J6 / U6
Radiometer 0-5Vdc
Production circuit pressure
Block I / AI7
pCO5+ / J29S1
Radiometer 0-5Vdc
Compressor suction pressure
Block I / AI8
pCO5+ / J29 / S2
NTC 10K 25°C
Compressor suction temperature
Block I / AI9
pCO5+ / J29 / S3
Radiometer 0-5Vdc
Compressor discharge pressure
Block I / AI10
pCO5+ / J29 / S4
NTC 50K 25°C
Compressor discharge temperature
Block I / AI11
pCO5+ / J6 / U7
NTC 10K 25°C
DHW inter-accumulator temperature
Block I / AI12
pCO5+ / J6 / U8
NTC 10K 25°C
DHW recirculation temperature
Block I / AI13
pCOe-1 / J9 / B1
NTC 10K 25°C
Mixture group 2 temperature
Block I / AI14
pCOe-1 / J9 / B2
NTC 10K 25°C
Mixture group 3 temperature
Block I / AI15
pCOe-1 / J10 / B3
NTC 10K 25°C
Mixture group 4 temperature
Block I / AI16
pCOe-1 / J10 / B4
NTC 10K 25°C
Mixture group 5 temperature
Block I / AI17
pCOe-2 / J9 / B1
NTC 10K 25°C
Heating buffer temperature
Block I / AI18
pCOe-2 / J9 / B2
NTC 10K 25°C
Cooling buffer temperature
Block I / AI19
pCOe-2 / J10 / B3
NTC 10K 25°C
Pool temperature
Block I / AI20
pCOe-2 / J10 / B4
NTC 10K 25°C
Outside temperature
DIGITAL INPUTS
CONNECTIONS
DESCRIPTION
Connection terminal
Controller terminal
Type
Signal
Block I / DI1
pCO5+ / J5 / DI1
24Vdc / 24Vac
Electrical consumption control (EVU)
Block I / DI2
pCO5+ / J5 / DI2
24Vdc / 24Vac
WINTER / SUMMER selection
Block I / DI3
pCO5+ / J5 / DI3
24Vdc / 24Vac
DHW production
Block I / DI4
pCO5+ / J5 / DI4
24Vdc / 24Vac
Pool production
Block I / DI5
pCO5+ / J5 / DI5
24Vdc / 24Vac
DG1 heating request
Block I / DI6
pCO5+ / J5 / DI6
24Vdc / 24Vac
DG1 cooling request
Block I / DI7
pCO5+ / J5 / DI7
24Vdc / 24Vac
SG2 heating request
Block I / DI8
pCO5+ / J5 / DI8
24Vdc / 24Vac
SG2 cooling request
Block I / DI9
pCO5+ / J7 / DI9
24Vdc / 24Vac
SG3 heating request
Block I / DI10
pCO5+ / J7 / DI10
24Vdc / 24Vac
SG3 cooling request
Block I / DI11
pCO5+ / J7 / DI11
24Vdc / 24Vac
SG4 heating request
Block I / DI12
pCO5+ / J7 / DI12
24Vdc / 24Vac
SG4 cooling request
Block I / DI13
pCOe-1 / J4 / DI13
24Vdc / 24Vac
SG5 heating request
Block I / DI14
pCOe-1 / J4 / DI14
24Vdc / 24Vac
SG5 cooling request
Block I / DI15
pCOe-1 / J4 / DI15
24Vdc / 24Vac
Not used
Block I / DI16
pCOe-1 / J4 / DI16
24Vdc / 24Vac
Not used
Block I / DI17
pCOe-2 / J4 / DI17
24Vdc / 24Vac
Not used
Block I / DI18
pCOe-2 / J4 / DI18
24Vdc / 24Vac
Not used
Block I / DI19
pCOe-2 / J4 / DI19
24Vdc / 24Vac
Not used
Block I / DI20
pCOe-2 / J4 / DI20
24Vdc / 24Vac
Not used
