Technical service manualecoGEO
62
EN
ANALOGUE OUTPUTS
CONNECTIONS
DESCRIPTION
Connection terminal
Controller terminal
Type
Signal
Block I / AO1
pCO5+ / J4 / Y1
0-10Vdc
Brine pump adjustment
Block I / AO2
pCO5+ / J4 / Y2
0-10Vdc
Production pump adjustment
Block I / AO3
pCO5+ / J4 / Y3
0-10Vdc
Regulation of mixture group 2
Block I / AO4
pCO5+ / J4 / Y4
0-10Vdc
Regulation of mixture group 3
Block I / AO5
pCOe-1 / J2 / Y5
0-10Vdc
Regulation of mixture group 4
Block I / AO5
pCO-12 / J2 / Y6
0-10Vdc
Regulation of mixture group 5
DIGITAL OUTPUTS
CONNECTIONS
DESCRIPTION
Connection terminal
Controller terminal
Type
Signal
Block II / DO1
pCO5+ / J12 / NO1
Activation 230Vac / 8A max
Brine circulation pump
Block II / DO2
pCO5+ / J12 / NO2
Activation 230Vac / 8A max
Production circulator pump
Block II / DO3
pCO5+ / J12 / NO3
Activation 230Vac / 8A max
DHW production
Block II / DO4
pCO5+ / J13 / NO4
Activation 230Vac / 8A max
DHW Recirculation
Block II / DO5
pCO5+ / J13 / NO5
Activation 230Vac / 8A max
Pool production
Block II / DO6
pCO5+ / J13 / NO6
Activation 230Vac / 8A max
DG1 group production
Block II / DO7
pCO5+ / J14 / NO7
Activation 230Vac / 8A max
SG2 group production
Block II / DO8
pCO5+ / J15 / NO8
Activation 230Vac / 8A max
SG3 group production
Block II / DO9
pCO5+ / J16 / NO9
Activation 230Vac / 8A max
SG4 group production
Block II / DO10
pCO5+ / J16 / NO10
Activation 230Vac / 8A max
SG5 group production
Block II / DO11
pCO5+ / J16 / NO11
Activation 230Vac / 8A max
Active cooling production
Block II / DO12
pCO5+ / J17 / NO12
Activation 230Vac / 8A max
Passive cooling production
Block II / DO13
pCO5+ / J18 / NO13
Activation 230Vac / 8A max
Alarm signal
Block II / DO14
pCOe-1 / J5 / NO1
Activation 230Vac / 8A max
Auxiliary brine circulation pump
Block II / DO15
pCOe-1 / J6 / NO2
Activation 230Vac / 8A max
Cooling auxiliary circulator pump
Block II / DO16
pCOe-1 / J7 / NO3
Activation 230Vac / 8A max
Heating / cooling consumption
Block II / DO17
pCOe-1 / J8 / NO4
Activation 230Vac / 8A max
DHW inter-accumulator resistor
Block II / DO18
pCOe-2 / J5 / NO1
Activation 230Vac / 8A max
Buffer storage tank resistor
Block II / DO19
pCOe-2 / J6 / NO2
Activation 230Vac / 8A max
Not used
Block II / DO20
pCOe-2 / J7 / NO3
Activation 230Vac / 8A max
Not used
Block II / DO21
pCOe-2 / J8 / NO4
Activation 230Vac / 8A max
Not used
PROTECTIONS
CONNECTIONS
DESCRIPTION
Connection terminal
Type
Signal
Block I / PS1
Safety switch
Low pressure switch
Block I / PS2
Safety switch
High pressure switch
Block I / ESS1
Safety switch
External safety switch
Block I / ESS2
Safety switch
External safety switch
