ECOFOREST ecogeo basic - Operation Map

Technical service manualecoGEO
44
EN
3.4. Operation map
ecoGEO B|C 1-9 kW / ecoGEO B|C 3-12 kW / ecoGEO B|C 5-22 kW
NOTE
Maximun speed of compressor is not able in all the areas of the operation map.
-25; 10
-25; 40
-7; 65
35; 65
35; 10
-25; 10
5
10
15
20
25
30
35
40
45
50
55
60
65
70
-30 -25 -20 -15 -10 -5 0 5 10 15 20 25 30 35 40
Heating / Dissipation outlet temperature (ºC)
Brine / Cooling outlet temperature (ºC)
