Technical service manual ecoGEO
57
EN
4. EcoGEO HP technical specifications
4.1. Component location
No.
Description
No.
Description
1
Production outlet
15
Production outlet temp. probe
2
Production return
16
Production inlet temp. probe
3
Brine outlet
17
Suction pressure transducer
4
Production return
18
Discharge pressure transducer
5
Evaporator (direct cycle)
19
Brine pressure transducer
6
Condenser (direct cycle)
20
Production pressure transducer
7
Compressor
21
Suction mini-pressure switch
8
Electronic expansion valve
22
Discharge mini-pressure switch
9
Filter dryer
23
Electrical panel
10
Cycle inversion valve
24
Service outlet
11
Compressor suction temp. probe
25
Liquid level glass
12
Compressor discharge temp. probe
26
Compressor oil display
13
Brine outlet temp. probe
27
Oil solenoid valve
14
Brine inlet temp. probe
