INSTRUCTIONS MANUAL
-106-
FIG. 42
2
FIG. 43
FILLING THE OIL 2 (UV) CONTAINER (R134a/R1234yf)
N.B.: Using UV not recommended by the manufacturer will invalidate the warranty.
Procedure:
1. Press quick connection button (ref 1, Fig.41) to disconnect the UV container.
2. R134a OIL 2 (UV) container (ref l, Fig.41);
R1234yf OIL 2 (UV)container (ref m, Fig.41).
3. Remove the container from its lodging
4. Unscrew the cap (ref 2, Fig.42) and fill the container (Fig.43) with the required quantity
of UV for compressors.
5. Screw the cap back into the container.
6. Replace the container and hook it up to the quick connection taking care not to exert
pressure on the scale in order not to damage it.
NOTE: in order to reduce humidity and air contamination of UV, the collapsible container has to
be filled almost to the brim.
FIG. 41
l
m
1
