INSTRUCTIONS MANUAL
-8-
GENERAL INFORMATION
Machine identification information is printed on the data plate on the rear of the machine (see
Fig.1). Overall machine dimensions:
Height: 1070 mm Width: 620 mm
Depth: 670 mm Weight: 110 kg
Operating temperature 10/50°C Storage temperature -25/+50°C
Like any equipment with moving parts, the machine inevitably produces noise. The
construction system, paneling, and special provisions adopted by the Manufacturer are such
that during work the average noise level of the machine is not in excess of 70 dB (A).
Model Voltage (V) Power (W) Frequency (Hz) Fuse (A)
100 Volt Machine 100 1100 50/60 16
110 Volt Machine 110 1100 50/60 16
230 Volt machine 230 1100 50/60 8
CAUTION: avoid the use of external extensions and verify that all electrical systems and
devices connected comply with the regulations in force and in good state of preservation
