Ecotechnics SUN ECK TWIN 12 - MACHINE COMPONENTS AND CONTROLS; BODY SHELL COMPONENTS

INSTRUCTIONS MANUAL
-17-
FIG. 4
FIG. 5
FIG. 6
1
2
3
THE MACHINE
BODY SHELL COMPONENTS
1. Upper plastic carter , refer to Fig.4
Disassembly: Screw off 4 screws marked (+)
2. Front plastic carter , refer to Fig.5
Disassembly: Screw off 8 screws marked (+)
3. Rear plastic carter , refer to Fig.6
Disassembly: Screw off 5 screws marked (+)
