INSTRUCTIONS MANUAL
-37-
During the recovery phase, the machine displays the quantity of refrigerant recovered, in
grams.
Upon completion of recovery, the machine will stop and discharge, while automatically
displaying the used oil extracted from the A/C system during the recovery phase. The oil
discharge operation lasts 4 minutes
Unscrew and disconnect HP and LP coupling from A/C system end press ENTER.
You are asked to enter the vehicle's PLATE, the FRAME NUMBER, the KM/Miles and the
Operator Code. Press ENTER.
ENTER
DD/MM/YY XX:XX PM
-
-
-
123456
Plate:
VIN:
Miles:
Operator code:
STOP
RECOVERY/RECYCLE
DD/MM/YY XX:XX PM
Gas recovered: 0g
A/C pressure 0.0 bar
Oil recovered: 0 ml
Tank Temperature 25.2 °C
RECOVERY/RECYCLE
Gas recovered: 0g
A/C pressure -0.5 bar
Tank Temperature 25.2 °C
DD/MM/YY XX:XX PM
Close and disconnect HP and LP couplings
from A/C system and press ENTER
ENTER
DD/MM/YY XX:XX PM
STOP
