INSTRUCTIONS MANUAL
-100-
Locate the filling cap (ref 3, Fig.28) and screw it completely off.
The
following screen is displayed:
The oil must be added through the hole in which the filling cap was lodged (ref 4, Fig.29)
Add oil a little at a time, waiting for the level to rise before each successive addition, until the oil
level is about ½ cm above the red mark on the indicator (ref 1, Fig.26).
Replace the filling cap (ref 3, Fig.28) and tighten down.
Replace the rear plastic cover (ref 2, Fig.27)
Refill vacuum pump with new oil
To the center of the control glass
Then replace filling cap.
When done press ENTER to exit.
