42
Pin
I/0
Signal
Description
b
Input
In2 + input
Positive input of input amplifier 2
c
Input
In2 - input
Negative input of input amplifier 2
d
Input
In3 + input
Positive input of input amplifier 3
e
Input
In3 - input
Negative input of input amplifier 3
f
Input
In4 + input
Positive input of input amplifier 4
g
Input
In4 - input
Negative input of input amplifier 4
h
-
GND
Power supply ground to the instrument
and casing
i
Input
In5 + input
Positive input of input amplifier 5
j
Input
In5 - input
Negative input of input amplifier 5
k
Input
In6 + input
Positive input of input amplifier 6
m
Input
In6 - input
Negative input of input amplifier 6
n
Input
In7 + input
Positive input of input amplifier 7
p
Input
In7 - input
Negative input of input amplifier 7
q
Input
In8 + input
Positive input of input amplifier 8
r
Input
In8 - input
Negative input of input amplifier 8
s
-
GND
Power supply ground to the instrument
and casing
t
Output
+15 V supply
Motor +
SC +
+15 V supply voltage (600 mA max.)
Probe motor drive (0–24 V, 2.0 A max., 10
W max.)
Current source (1 A max., 10 W max.)
