Edge-Core ES3526YA - Figure 4-2 Network Wiring Connections

Twisted-Pair Devices
4-3
4
3. Label the cables to simplify future troubleshooting. See “Cable Labeling and
Connection Records” on page 4-7.
Figure 4-2 Network Wiring Connections
Equipment Rack
(side view)
Switch
Patch Panel
Punch-Down Block
Wall
