Installation Instructions
Ford Juice
Supplied Items
Required Tools
1999 - 2003 (7.3L)
1
2
4
3
6
8
5
7
Note: Depending on your year of truck,
you may not need everything provided.
REFER TO QUICK
INSTALL GUIDE
FOR INSTALL
1 Main Harness
2 Juice Module
3 Throttle Position Sensor (TPS)
Harness - Year Specifi c
4 Velcro Strips
5 Zip Ties
6 EGT Sensor Probe
7 Juice Attitude Bridge (JAB)
8 CS/CTS Installation Guide
99-00
01-03
- Electric/Cordless Drill
- 1/8” drill bit or similar size
(for pilot hole)
- 21/64” (best size) or 5/16”
drill bit (for fi nal hole)
- 9/16” wrench or socket
- 5/8” open end wrench
- 1/8”-27 NPT Thread Tap
- Phillips screwdriver
- 5/16” or 8mm wrench
- 13mm wrench
