2205 System Technical and User’s Guide
Document : 0022175 Rev A Page 20
Ping Name
ID
Ping
Freq
(kHz)
BW
(kHz)
PW
(ms)
Max Ping
Rate
(Hz)
Min
Range
(m)
2300_DDPA_SS125Q_14BW_2MS
50635
125
14
2
15.0
48.5
2300_DDPA_SS125Q_12BW_3MS
50637
125
12
3
10.0
72.8
2300_DDPA_SS125Q_12BW_4MS
50636
125
12
4
7.5
97.0
2300_DDPA_SS125Q_10BW_6MS
50639
125
10
6
5.0
145.5
2300_DDPA_SS125Q_10BW_10MS
50638
125
10
10
3.0
242.5
2300_DDPA_SS125Q_8BW_16MS
50640
125
16
16
1.88
388.0
Table 9-2. 120kHz (SSL) Pulse Characteristics
Ping Name
ID
Ping
Freq
(kHz)
BW
(kHz)
PW
(ms)
Max Ping
Rate
(Hz)
Min
Range
(m)
2300DDPA_SS230Q_25BW_1_0MS
50929
230
25.0
1.0
30.0
24.3
2300DDPA_SS230Q_25BW_1_5MS
50930
230
25.0
1.5
20.0
36.4
2300DDPA_SS230Q_23BW_2_0MS
50931
230
23.0
2.0
15.0
48.5
2300DDPA_SS230Q_20BW_3_0MS
50932
230
20.0
3.0
10.0
72.8
2300DDPA_SS230Q_20BW_5_0MS
50933
230
20.0
5.0
6.0
121.3
2300DDPA_SS230Q_20BW_8_0MS
50934
230
20.0
8.0
3.75
194.0
Table 9-3. 230kHz (SSL) Pulse Characteristics
