2205 System Technical and User’s Guide
Document : 0022175 Rev A Page 21
Ping Name
ID
Ping
Freq
(kHz)
BW
(kHz)
PW
(ms)
Max Ping
Rate
(Hz)
Min
Range
(m)
2300_SS410Q_60BW_0_40MS
50642
410
60
0.4
75.0
9.7
2300_SS410Q_60BW_0_60MS
50641
410
60
0.6
50.0
14.6
2300_SS410Q_50BW_1_40MS
50643
410
50
1.4
21.43
34.0
2300_SS410Q_40BW_2_20MS
50644
410
40
2.2
13.64
53.4
2300_SS410Q__30BW__3_2MS
50645
410
30
3.2
9.38
77.6
2300_SS410Q_25BW_4_90MS
50646
410
25
4.9
6.12
118.8
Table 9-4. 410kHz (SSH) Pulse Characteristics
Ping Name
ID
Ping
Freq
(kHz)
BW
(kHz)
PW
(ms)
Max Ping
Rate
(Hz)
Min
Range
(m)
2300_SS540Q_60BW_0_5MS
50935
540
60
0.5
60.0
12.1
2300_SS540Q_60BW_0_9MS
50936
540
60
0.9
33.3
70.3
2300_SS540Q_50BW_1_5MS
50937
540
50
1.5
20.0
36.4
2300_SS540Q_45BW_2_1MS
50938
540
45
2.1
14.29
50.9
2300_SS540Q_40BW_2_9MS
50939
540
40
2.9
10.34
70.3
2300_SS540Q_30BW_3_7MS
50940
540
30
3.7
8.11
89.7
2300_SS540Q_30BW_5MS
50941
530
30
5.0
6.0
121.3
Table 9-5. 540kHz (SSH) Pulse Characteristics
