25
Click MAC-Base Assignment button, the below window appears. In this page, you can
assign IP addresses on the LAN to specific individual computers based on their MAC
address.
Fig 3.4.2-5
The following table describes the fields of this screen.
Label
Description
Host MAC Address
Type the MAC address of a computer on your LAN
Assigned IP Address
This field specifics the IP of the IP address pool.
Assign IP
Click this button after entered Host MAC Address and
Assigned IP Address, a row will be added in MAC-Base
Assignment Table.
Modify Assigned IP
Select a row in MAC-Base Assignment Table, the MAC
address and IP address will appears Host MAC
Address and Assigned IP Address. After modified the
MAC Address and IP Address, click this button to save
the changes.
Delete Assigned IP
Select a row in MAC-Base Assignment Table, then click
this button, this row will be deleted.
Close
Click this button to close this window.
MAC-Base
Assignment Table
This table shows the assigned IP address based on the
MAC address.
