84
Controlling the SD-90 via MIDI
<Example> If you want to select the sound for variation number 8, instrument number 3 (Piano3 w), transmit
the following data to the SD-90 (given in decimal form).
1.
Value of control change 0: 008 (upper byte of bank number = variation number: 8)
2.
Value of control change 32: 0
3.
Value of program change: 003 (program number = instrument number: 3)
About the bank select lower byte (LSB)
The SD-90 processes the lower byte (LSB) of the bank select message as follows:
<Example> Switching the sound of a part
To switch the sound of part 2 to
017 Organ 1
(variation 000), transmit the following.
MIDI CH = 02
CC#00 000 ... set the variation number to 000
CC#32 0
PC# 017 ... set the instrument number to 017
<Example> Changing the variation of the part’s sound
To switch the sound of part 1 to
008 Detuned EP1
(variation 008), transmit the following.
MIDI CH = 01
CC#00 008 ... set the variation number to 008
CC#32 0
PC# 006 ... set the instrument number to 008
<Example> Changing the sound set and variation of the part’s sound
To switch the sound of part 3 to
039 Syn. Bass 3
(variation 008), transmit the following.
MIDI CH = 03
CC#00 008 ... set the variation number to 008
CC#32 0
PC# 039 ... set the instrument number to 039
Number Processing
0 Follows the currently-valid GS mode.
