Controlling the SD-90 via MIDI
■ Editing audio effect parameters
To edit the drive (OD Drive) of the “Guitar Multi” audio effect via MIDI, transmit the following system
exclusive data.
<Example> Setting OD to 89 for the Guitar Multi
Transmit the following system exclusive data.
fig.9-74c_99
1. Transmit AFX TYPE to set the effect type to
Guitar Multi.
fig.9-74d_99
2. Transmit AFX PARAMETER 7 to select OD
within Guitar Multi, and set the effect
parameter to 89.
* The lower 4 bits of the four data bytes
indicate a signed numerical value. For
details on the data byte expression, refer to
"Data byte expression" (p. 91) .
fig.9-74e_99
3. Transmit AFX SW to turn on the audio
effect.
F0 41 10 00 48 12 [02 10 20 00] [20] [2E] F7
(1) (2) (3) (4) (5) (6) (7) (8) (9)
Audio AFX Type
20H(=32)
Audio Common
F0 41 10 00 48 12 [02 10 20 29] [08 00 05 09] [4C] F7
(1) (2) (3) (4) (5) (6) (7) (8) (9)
Audio
Parameter7
(=OD)
59H(=89)
Audio Common
AFX Parameter
F0 41 10 00 48 12 [02 10 20 43] [01] [0A] F7
(1) (2) (3) (4) (5) (6) (7) (8) (9)
Audio AFX On/Off
01H(=On)
Audio Common
AFX Parameter
