Controlling the SD-90 via MIDI
Controlling the audio mixer
fig.9-73d_99
To use MIDI messages to control the functionality of
the audio mixer, you can transmit the system
exclusive messages shown in the examples below.
■ Switching the routing
You can use MIDI messages to switch the routing. Transmit the following system exclusive messages
according to the desired routing.
<Example> Switching the routing to 05:Send Return AFX
fig.9-74a_99
Transmit the following system exclusive data.
■ Editing mixer parameters
To edit the recording volume (Rec Vol) of the audio mixer via MIDI, transmit the following system
exclusive data.
<Example> Setting the audio mixer recording volume to 89
fig.9-74b_99
Transmit the following system exclusive data.
F0 41 10 00 48 12 [a1 a2 a3 a4] [dd …] [ss] F7
(1) (2) (3) (4) (5) (6) (7) (8) (9)
(1) Exclusive status
(2) ID (Roland : 41H)
(3) Device ID
(4) Model ID (SD-90 : 00H 48H)
(5) Command ID (Data set : 12H)
(6) Address
(7) Data
(8) Checksum
(9) End of Exclusive
F0 41 10 00 48 12 [02 10 10 00] [05] [59] F7
(1) (2) (3) (4) (5) (6) (7) (8) (9)
Audio
05
(Send/Return AFX)
Audio Common
Mixer Preset Mode
F0 41 10 00 48 12 [02 10 00 01] [59] [14] F7
(1) (2) (3) (4) (5) (6) (7) (8) (9)
Audio Rec Vol
59H(=89)
Audio Common
