© Edwards Limited 2014. All rights reserved. Page 15
Edwards and the Edwards logo are trade marks of Edwards Limited.
Installation
A546–00–880 Issue E
3.5.2 Gas Purges
Switch on the inert gas purge to remove air from the pump and the exhaust pipeline before the process starts. Switch
off the purge flow at the end of the process only after the remaining flammable gases or vapours have been purged
from the exhaust pipeline.
If liquids that produce flammable vapours could be present in the pump foreline, then the inert gas purge to the dry
pumping system should be left on all the time this liquid is present. Flammable liquids could be present in the foreline
as a result of condensation or may be carried over from the process.
When calculating the flow rate of inert gas required for dilution, consider the maximum flow rate for the flammable
gases/vapours that could occur. For example, if a mass flow controller is being used to supply flammable gases to
the process, assume a flow rate for flammable gases that could arise if the mass flow controller is fully open.
Continually measure the inert gas flow rate: if the flow rate falls below that required, then the flow of flammable
gases or vapours to the pump must be stopped.
3.6 Leak-test the iGX system
Note: If further information on leak testing is needed, look it up on the Edwards website at
www.edwardsvacuum.com, or contact the supplier or Edwards for advice.
Refer to Figure 2, item 28.
If using inert gas purges to dilute dangerous gases to a safe level, ensure that the pump is shut
down if an inert gas supply fails.
Leak test the system after installation and seal any leaks found to prevent leakage of dangerous
substances out of the system and leakage of air into the system.
