Edwards iXM Series User Manual

example, type B RCD according to EN50178, supplementary protector according to
UL1077, circuit br
eakers according to UL489, ground fault interrupter according to
UL943).
If the electrical supply to the system is connected through an Earth Leakage Circuit
Breaker (ELCB) or Residual Current Device (RCD) (depending on territory) it must be
applicable for:
▪ protecon of equipment with a d.c. component in the fault current
▪ short duraon switch-on surges
▪ high leakage current.
For example, type B RCD according to EN50178, supplementary protector according to
UL1077, circuit breakers according to UL489, or ground fault interrupter according to
UL943.
Electrical supply safety
WARNING: ELECTRICAL SAFETY
Risk of electric shock. Make sur
e that the electrical installaon of the pump agrees
with all local and naonal safety requirements. It must be connected to a correctly
protected electrical supply and with a earth (ground) point.
WARNING: HAZARDOUS VOLTAGES
Risk of electric shock. This equipment is applic
able for Installaon Category II as
dened in IEC 60664-1. The system must be connected to an isolator that disconnects
all current carrying conductors and can be locked out in the o posion (LOTO). The
isolator must be near the equipment, in easy reach of the operator and idened as
the disconnect device for the equipment.
WARNING: HAZARDOUS VOLTAGES
Risk of electric shock. Isolat
e the electrical supply before you disconnect the electrical
supply cable from the dry pumping system.
WARNING: HAZARDOUS VOLTAGES
Risk of electric shock. Make sur
e that the pump and electrical cables are correctly
protected against earth (ground) faults. Make sure that the earth (ground) conductor
of the electrical supply cable is longer than the phase conductors in the connector.
WARNING: PROTECTIVE EARTH CONDUCTOR
Risk of electric shock. Inst
all a second protecve earth (ground) conductor (with a
cross-seconal area as given in electrical connecon Table: Wire assembly according
to VDE 0295, i.e. from 6 mm
2
to 10 mm
2
) to the protecve earth (ground) stud,
Figure: Controls/connectors on the rear of the system.
10/2020 - ©Edwards Limited
Page 37M56635880_D
M56635880_D - Inst
allaon
