Note:
The bearing an-rotang tube may be used to prevent the bearing from rotang while the
extractor sleeve is removed.
Figure 9
Bearing module inseron
Bearing retaining nut assembly
Refer to Figure 10 on page 15.
1. Using the combinaon of tools, engage the bearing retaining nut onto the pins of
the pin spanner adaptor.
2. In reverse order of removal, t the bearing retaining nut into posion, taking care
not to cross thread the nut. Torque the bearing retaining nut to 6 Nm.
Figure 10
Bearing retaining nut assembly
1. Pin spanner adaptor 2. Bearing retaining nut
B8G2-00-840A - Service
Page 15
