WARNING:
Following a service counter reset the pump may enter a short setup / test roune.
During this period some movement of the rotor may occur. To ensure safety of the user,
in line with the product instrucon manual, install the pump in the vacuum system
before connecng the motor controller to the power supply. This will ensure that the
pump cannot operate and injure people.
Table 2
Front panel symbols and their funcons
Symbol Name Funcon
UP
Move up through a menu.
Cycle selected numerical values up.
Cycle a selected list item upwards.
DOWN
Move down through a menu.
Cycle selected numerical values down.
Cycle a selected list item downwards.
SELECT
Enter the highlighted sub menu.
Edit the highlighted list or numerical item.
Move to the next digit of a numerical value.
Jump to the setup screen for the highlighted
gauge or pump.
MENU
Switch between the default view screen and
the main menu.
Exit the current sub menu or setup screen.
Abort edit of a selected list item.
Move to the previous digit of a numerical
value.
CYCLE Turn a highlighted gauge or pump on or o.
Reset the service interval using a Turbo Instrument Controller (TIC)
1. Starng from the top level view screen, press the MENU buon to enter the MAIN
menu.
2. Using the DOWN buon, scroll down to the "Turbo Status" opon then press the
SELECT buon to enter the TURBO STATUS menu.
3. Using the DOWN buon, scroll down to the "Service menu - enter" opon then
press the SELECT buon to enter the nEXT SERVICE menu.
4. Using the DOWN buon, scroll down to the "Reset Service Due . . . " opon then
press the SELECT buon to enter the nEXT SERVICE RESET menu.
B8G2-00-840A - Service
Page 19
