Edwards nXLi Series - Pump Controller Configuration

Descripon Data
Mang connector plug; screw
connecon, right angle
Phoenix part number SACC-M 8MR-4CON-M-SW
Mang connector plug; solder
connecon, right angle
Phoenix part number SACC-M 8MR-4CON-M
Pump controller conguraon
All the conguraon sengs stored within the pump controller are retained when power to
the pump is remo
ved so that it is possible to use a separate system to congure the pump
controller before ng the pump to the applicaon.
This gives the benet of tailoring the pump funconality to the applicaon and allows the
pump to be operated using a simple parallel interface system.
A770-10-880A - General descripon
Page 14
