Edwards nXLi Series - Technical Reference; Operating and Storage Conditions; General Technical Data; Figure 6 Dimensions - Nxl110 I

Technical Reference
Operang and storage condions
Table 7
Operang and storage condions
Range Data
Ambient operang t
emperature range 5 °C to 40 °C
Ambient operang humidity range 10 to 90% RH (non-condensing)
Maximum operang altude 2000 m
Ambient storage temperature range -30 °C to 70 °C
Polluon degree 2
Equipment type Indoor use
Enclosure protecon IP20
General technical data
Table 8
Mechanical data
nXL110i nXL200i
Overall dimensions (L x W x H) 654 x 308 x 344 mm 704 x 308 x 343 mm
Maximum lt angle 25 °
Nominal rotaonal speed 9000 rpm
Mass 75 kg 81 kg
Inle
t connecon NW40/NW50
Outlet connecon NW25
Figure 6
Dimensions - nXL110i
All measurements indicated are shown in mm (inches)
A770-10-880A - Technical Reference
Page 33
