The Smart GFI is an adjustable function ranging from 0.5 - 5.0mA. Setting the Smart GFI value to
0mA will simply turn the function OFF. To set the Smart GFI enter the desired value using the
touchscreen keypad and touch the enter key (↵) to save the value and move on to the next
parameter. To clear the entered value the ← key should be used. To exit back to the previous
menu use the “X” key.
4.3.3.2 PLC Remote
The PLC Remote function can be set to ON or OFF. To set the PLC Remote function, touch the
ON/OFF key. To save the setting touch the enter key (↵) and move to the next parameter.
When the PLC remote is turned ON, the front panel TEST button is disabled and a test may only be
started through the rear panel I/O. If you attempt to start a test from the front panel TEST button
when the PLC Remote function is turned “ON”, a pop-up message will be displayed.
4.3.3.3 Single Step
This function is used to temporarily override the automatic connection feature. When the Single
Step function is ON the instrument will pause after each step is completed. To continue the test
sequence, press the Test button to execute the next connected step. Each time the TEST button is
pressed the next connected step will execute. If you press the RESET button before completing all
connected steps, it will return you to the original starting step. If a step fails and you wish to
continue to the next step, do not press RESET.
The Single Step function can be set to ON or OFF. To set the Single Step, touch the ON/OFF key. To
save the setting touch the enter key (↵) and move to the next parameter.
4.3.3.4 Fail Stop
Fail Stop is a function that will stop a sequence if a failure occurs. If this function is turned off, the
sequence of tests will continue to the end of the sequence regardless of whether or not a failure
has occurred. If the Fail Stop is OFF and a failure occurs during the test sequence, the RESET
button will light and a short alarm will sound but the sequence will continue to the end.
At the end of the test sequence the RESET button will light and alarm will sound indicating failure
during the sequence. Pressing the RESET button will silence the alarm. Pressing the RESET button a
second time will reset the instrument.
The Fail Stop function can be set to ON or OFF. To set the Fail Stop function touch the ON/OFF key.
To save the setting touch the enter key (↵) and move to the next parameter.
4.3.3.5 Measurement
The Measurement function can be set to either True RMS or Average. Touch the screen to select
the desired value and the enter key (↵) to save the selection and move to the next parameter.
