of the SE to any value between 0 and 30. The address can only be set from the front panel. The
address is stored in non-volatile memory and does not change when the power has been off or
after a remote reset.
 The address is set to 8 when the instrument is shipped from the factory.
8.3 Interface Functions
The capability of a device connected to the bus is specified by its interface functions. These
functions provide the means for a device to receive, process, and send messages over the bus. The
interface functions are listed in the chart below.
GPIB 488.1 INTERFACE FUNCTIONS
INTERFACE FUNCTION
SUBSET
DESCRIPTION
Source Handshake
SH1
Complete Source handshake capability
Acceptor Handshake
AH1
Complete Acceptor handshake capability
Talker
T6
Talker functions (unaddress if MLA)
Listener
L4
Listener functions (unaddress if MTA)
Service Request
SR1
Complete Service request capability
Remote Local
RL0
No remote/local capability
Parallel Poll
PP0
No parallel poll capability
Device Clear
DC1
Complete Device clear capability
Device Trigger
DT0
No device trigger capability
Controller
C0
No controller capability
Electrical Interface
E2
Three-state drivers
Controllable Items
Test and Reset control.
Setting of test parameters for tests.
Reading of instrument status and test results.
Data Codes
ASCII
Delimiter
NL (+ EOI)
8.4 USB/RS-232 / GPIB Interface Command List
Echo and Response Considerations
USB/RS-232 Responses
The USB/RS-232 bus will automatically send any response back to the controller's input buffer.
GPIB Queries and Responses
The SE GPIB bus will not send any data to the controller without being queried. A GPIB read
command must be sent after a command string to retrieve any data from a query command (?).
