AutoCal V3 User Guide
support@efilive.com - 6 - www.efilive.com
Specification & Requirements
AutoCal V3 Package Contents
The contents of your AutoCal product may vary due to being supplied directly from
your tuner or parts supplier. At a minimum your AutoCal will be shipped with:
AutoCal V3.
OBDII cable (RJ45 to SAE-J1962)
PC cable (USB A to B)
AutoCal V3 Specification
Large, easy to read color screen.
Powerful ARM Cortex-M3, 32-bit CPU.
Built in 512MB micro SD Card stores hundreds of tune files and/or
hundreds of hours of logged data.
Supports 600 VIN licenses.
Built-in audible alarms.
Upgradable firmware.
Vehicle Input Voltage - Min 9V, Max 24V.
Supported protocols CAN J1979, CAN J1939 (heavy duty) and VPW.
Serial interface (RS-232).
Battery backed real-time clock for accurate timestamps.
Appears as a Windows USB drive in Windows Explorer.
Files transfer up to 10 times faster than FlashScan/AutoCal V2.
Built-in power supply prevents data corruption if external power supply is
interrupted.
Plug-and-Play, uses Windows’ built in USB drivers.
Rugged Molex connectors.
USB Drivers
AutoCal V3 appear as a Windows USB drive in Windows Explorer. There are no
external drivers to install.
AutoCal V3 Functionality
Standalone Mode
Reading, flashing, logging and clearing codes.
Pass-thru Mode
Read, log and flash supported controllers using the EFILive V8 software.
