Efka AB600A5010 - Mode 7: Overlock (Tape Cutter; Seam End No Stop)

- AB600A5010 Parameter List
- 45 -
Mode 7 (overlock) parameter 232 = 0 (tape cutter) / parameter 018 = 1 (seam end without stop)
Mark
Function
Parameter
Control
FAm
LS
LS
UoS
-Pd
USS
Mode 7
Light barrier compensating stitches
Light barrier
Sequence “overlock mode at the seam end without
stop”
Function “pedal in pos. –1/–2” activated in the
seam
Tape cutter function
290 = 7
004 = 0
009 = 1
018 = 1
019 = 3
232 = 0
n1
n2
n7
Positioning speed
Maximum speed
Trimming speed
110
111
116
c3
c4
t3
kt1
kdF
Start counting for tape cutter
End counting for tape cutter
Start delay from lifted sewing foot
ON periods of outputs M1
Switch-on delay of sewing foot lifting
002
003
202
281
288
