- AB600A5010 Parameter List
- 56 -
Supplier level (Code No. 3112)
Parameters
Designation
Unit
Max
Min
Preset
Ind.
240 in1
Selection of input function on socket ST2/7 for input 1
0 = No function
1 = Needle up/down
2 = Needle up
3 = Single stitch (basting stitch)
4 = Full stitch
5 = Needle to position 2
6 = Machine run blockage effective with open contact
7 = Machine run blockage effective with closed contact
8 = Machine run blockage unpositioned effective with open contact
9 = Machine run blockage unpositioned effective with closed
contact
10 = Automatic speed n12 without pedal (N.O. contact)
11 = Limited speed n12 pedal controlled
12 = Sewing foot lifting with pedal in position 0 (neutral)
15 = Tape cutter / fast scissors, function only in chainstitch and
overlock mode
18 = Unlocking the chain, can be activated by keystroke, but will be
executed only at the seam end
23 = No function
24 = Needle to position 2 (see instruction manual)
27 = Unlocking the chain, function is performed upon pressing the
key
28 = External light barrier (according to setting of parameter 131)
33 = Speed n9 pedal controlled
34 = Automatic speed n9 can be suspended by pressing the pedal
to pos. 0 (neutral)
37 = Speed n12 pedal controlled (break contact)
38 = Automatic speed n12 without pedal
(break contact [N.C.])
41 = Tape cutting only at machine standstill
42-145 = No function
145
0
0
267 Abc
Overlock mode: Interrupt the start count
And seam end initiation by light barrier uncovered
1
0
0
269 PSv
Positioning shift
Incr.
100
0
10
270 PGm
Mode of a position sensor with normally open function (N.O.).
6
0
0
0 = No external sensor. Positions are created via the sensor integrated in the motor.
5 = No position sensor available. The drive stops unpositioned. The thread trimmer function is
suppressed with this setting.
6 = With external sensor (e.g. IPG, HSM...).
