- AB600A5010 Parameter List
- 57 -
Parameters
Designation
Unit
Max
Min
Preset
Ind.
272 trr
Transmission ratio between motor shaft and machine shaft
(calculation formula see instruction manual!)
The transmission ratio should be determined and indicated as
precisely as possible!
40000
150
1000
280 kd1
Delay time output M1
ms
5000
0
0
281 kt1
ON period output M1
ms
5000
0
100
282 kd2
Delay time output M2
ms
5000
0
100
283 kt2
ON period output M2
ms
5000
0
100
288 kdF
Delay time until sewing foot On
ms
5000
0
380
290 FAm
Selection of machine specific mode
0 = Lockstitch:
(FA1, FA2, FA3, FA1+FA2): e.g. BrotherDürkopp Adler,
Mitsubishi, Pfaff, Toyota
5 = Chainstitch general:
M1, M2, M3 and M4 parallel sequence
6 = Chainstitch with tape cutter and
Fast scissors and M1 / M2 at the seam end
7 = Overlook
8-46= No function
47= Hand-stitch machine: Guta Activation necessary!
48-65= No function
66 = Chainstitch: Strobel VTD 410EV
67 = Chainstitch: Hengtai MP500
68 = Lockstitch: Typical/Mauser Klasse 333
69 = Lockstitch: Juki class 1760
70= Reserved
71= No function
72= CL205/CL204
»Slide-in strips for V810/820 =5/5«
73= Reserved
74= Chainstitch: Yamato VG
»Slide-in strips for V810/820 =5/5«
75= SHDA CL160-30
»Slide-in strips for V810/820 =5/5«
76= Reserved
77= Reserved
78=Golden Wheel CSR88914
»Slide-in strips for V810/820 =5/5«
79 Gute GT8700C
Other modes are selectable, however have the same functions as
mode 0.
76
0
5
328 ob
Changing function keys on the control panel
0 = All keys are locked
1 = All keys are released, key E + start backtack,
key + end backtack (except mode 7)
2 = All keys are released, button E affects chain suction,
button + impacts tape cutter (only in mode 7)
3 = Button E and button + no function
4 = 4 = Button E, + and – no function
5 = Button E affects soft start, button + impacts tape cutter
and wiper
6 = Button E affects soft start, button + impacts tape cutter seat
start /end
6
0
1
340 1L
Lower switching threshold of input IN1
%
100
0
30
341 1L
Upper switching threshold of input IN1
%
100
0
80
360 11L
Lower switching threshold of input LSM
%
100
0
50
361 11h
Upper switching threshold of input LSM
%
100
0
70
362 15V
Switch +5V/+15V on B18
0 = +5V
1 = +15V
1
0
0
370 n2
Direct input of maximum speed
RPM
F-111
F-121
Display
374 nrd
Reset speed
rpm
390
70
100
B
