6
Rear Panel
Rear Panel
1. LOOP OUT: Loop output RF signal to another receiver or DAB+ IN.
2. ANT IN: Connect to terrestrial antenna.
3. ETHERNET: Connect to Ethernet.
4. SPDIF: Output digital audio signal to amplifier.
5. USB: Connect to specific USB device.
(USB1)
6. HDMI: Output video and audio signal to TV (support high definition
Output).
7. YPbPr: Output Y/Pb/Pr video signal to TV (support high definition output).
8. DAB+ IN: To connect the DAB+ antenna or RF Cable
9. COAXIAL: Output digital audio signal to amplilfier.
10. CVBS: Ouput CVBS video signal to TV.
11. AUDIO L/R: Output right/left audio signal to TV or Amplifier.
