11 EMC Tables
26 / 31
Electrical fast
transients/burst
s
IEC 61000-4-4
±2kV
100kHz
repetition
frequency
±2kV
100kHz
repetition
frequency
Mains power quality should
be that of a typical
commercial or hospital
environment.
Surge
IEC 61000-4-5
Line to line:
±0.5kV, ±1kV
Line to earth:
±0.5kV, ±1kV,
±2kV
Line to line:
±0.5kV, ±1kV
Line to earth:
±0.5kV, ±1kV,
±2kV
Mains power quality should
be that of a typical
commercial or hospital
environment.
Voltage dips
IEC 61000-4-
11
Voltage
interruptions
IEC 61000-4-
11
0% UT; 0.5
cycle
at 0°, 45°, 90°,
135°, 180°,
225°, 270°, and
315°
0% UT; 1 cycle
and 70% UT;
25/30 cycles
sine phase at 0°
0% UT;
250/300 cycle
0% UT; 0.5
cycle
at 0°, 45°, 90°,
135°, 180°,
225°, 270°, and
315°
0% UT; 1 cycle
and 70% UT;
25/30 cycles
sine phase at 0°
0% UT;
250/300 cycle
Mains power quality should
be that of a typical
commercial or hospital
environment. If the user of
devices require continued
operation during power mains
interruptions, it is
recommended that devices
be powered form an
uninterruptible power supply
or a battery
Rated Power
frequency
magnetic field
IEC 61000-4-8
30 A/m
50Hz or 60Hz
30 A/m
50Hz or 60Hz
Power frequency magnetic
field should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
Note: UT: rated voltage(s); E.g. 25/30 cycles means 25 cycles at 50Hz or 30 cycles at 60Hz
Guidance and manufacturer’s declaration – electromagnetic immunity
