Eizo FlexScan EV3237 User Manual

- 22 -
Chapter 2 Basic Adjustment/Setting
Function Setting Range Description Note
EcoView Sense On
Off
When set to “On”, the sensor on the front of the
monitor detects user movement. When the user
moves away from the monitor, it automatically
shifts to power saving mode and does not display
images on the screen in order to reduce power
consumption. When the user comes near the
monitor again, it recovers from power saving mode
and displays images.
The sensitivity of the sensor and time until
power saving mode is activated can be set in the
“Advanced Settings” according to the monitor usage
environment and movement of the user.
• At the time of shifting to power saving mode,
a message that indicates the transition is
displayed.
• When “Power Save” on the Preferences menu
is set to “Off”, the EcoView Sense setting is
disabled.
Advanced
Settings
Time 5, 30 sec
1, 3, 5, 10, 15, 30, 45,
60 min
Species the time from when the user leaves the
monitor until the “No Presence detected” message
appears. The monitor shifts to power saving mode
about 20 seconds after the message is displayed.
-
Sensitivity Level 5
Level 4
Level 3
Level 2
Level 1
When the setting level is high (“Level 5” at
maximum), even minor movements of the user are
detected, which prevents the monitor from readily
shifting to power saving mode. On the other hand,
when the setting level is low (“Level 1” at minimum),
only major movements of the user are detected,
which allows the monitor to readily shift to power
saving mode.
• The EcoView Sense function is activated when
the sensor on the front of the monitor detects
the movement of heat. Therefore, the sensitivity
should be changed depending on the typical
user’s clothes or typical room temperature. If
the monitor shifts to or recovers from power
saving mode contrary to your expectations, try
changing the setting level.
• To use the monitor comfortably, increase the
sensitivity for high temperatures, because the
detection sensitivity decreases. Reduce the
sensitivity for low temperatures because the
detection sensitivity increases.
Reset - Return the advanced settings to their default values. -

Eizo FlexScan EV3237 Specifications

General

3D	No
Pixel pitch	0.1815 x 0.1815 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	31.5 \
Display technology	LED
Viewable size, vertical	392 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	696.9 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	720 x 400, 800 x 600 (SVGA), 1280 x 1024 (SXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 2560 x 1440, 3840 x 2160
On/off switch	Yes
DVI-D ports quantity	1
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-B
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	3
Product color	Black
Market positioning	-
Tilt angle range	-5 - 35 °
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	105 W
Annual energy consumption	57 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	39 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	245 mm
Height (with stand)	578 mm
Weight (with stand)	10600 g
Depth (without stand)	59.5 mm
Width (without stand)	731 mm
Height (without stand)	428 mm
Weight (without stand)	7800 g
