Eizo FlexScan EV3237 User Manual

- 8 -
Chapter 1 Introduction
- EcoView Optimizer 2
The monitor automatically adjusts the screen brightness according to the white level of the input signal. This function can reduce power consumption while maintaining
the brightness specied by the input signal.
See “EcoView Optimizer 2” (page 21).
- EcoView Sense
The sensor on the front of the monitor detects user movement. When the user moves away from the monitor, the monitor shifts to power saving mode automatically and
does not display images on the screen in order to reduce power consumption. The sensitivity of the sensor and time until power saving mode is activated can be set
according to the monitor usage environment and movement of the user.
See “EcoView Sense” (page 22).
*2 Reference values:
Maximum power consumption: 105 W (when a USB device is connected, speaker working)
Standard power consumption: 30 W (brightness 120 cd/m
2
, when no USB device is connected, speaker not working, at default settings)
• Equipped with a USB Hub function that supports USB 3.0
Achieves high-speed data transfers of up to 5 Gbps, which enables transfers of large amounts of data to and from USB-connected devices in a short amount time.
The USB downstream “CHARGE” port supports quick charging that allows charging of smartphones and tablets in a short time.
See “6-4. Making Use of USB (Universal Serial Bus)” (page 49) and “USB CHARGE Port” (page 31).
• Stand with wide range of movement
The monitor can be adjusted to a position that provides a comfortable and less tiring work environment.
Tilt: 35˚ up/5˚ down, swivel: 344˚, adjustable height: 141 mm (tilt: 35˚) / 139 mm (tilt: 0˚)
• Displays HDCP (High-bandwidth Digital Protection)
*3
protected contents.
*3 Supports HDCP Version 1.x
• Supports the “ScreenManager Pro” software for adjusting the screen using the mouse and keyboard
This software can be downloaded from our web site (http://www.eizoglobal.com).
• Supports the “EIZO Monitor Congurator” software for creating monitor conguration les
When installing multiple units of this monitor, this software allows users to apply a single conguration le to all monitors at the same time. This increases the efciency of
monitor installation work by eliminating the need for conguring each monitor individually.
For more information, refer to our web site (http://www.eizoglobal.com).

Eizo FlexScan EV3237 Specifications

General

3D	No
Pixel pitch	0.1815 x 0.1815 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	31.5 \
Display technology	LED
Viewable size, vertical	392 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	696.9 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	720 x 400, 800 x 600 (SVGA), 1280 x 1024 (SXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 2560 x 1440, 3840 x 2160
On/off switch	Yes
DVI-D ports quantity	1
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-B
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	3
Product color	Black
Market positioning	-
Tilt angle range	-5 - 35 °
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	105 W
Annual energy consumption	57 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	39 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	245 mm
Height (with stand)	578 mm
Weight (with stand)	10600 g
Depth (without stand)	59.5 mm
Width (without stand)	731 mm
Height (without stand)	428 mm
Weight (without stand)	7800 g
