Elcometer 456 Model E - Page 11

Model
a
Green LED
EBST
b
Battery Life Indicator
EBST
c
Bluetooth On
ST
d
Substrate Type - F, N, FNF
EBST
e
Calibration Method
BST
f
Reading Outside Calibration Warning On
T
g
Upper Limit On
ST
h
Units of Measurement - µm, mils, mm, inch
EBST
i
Batch Type - normal, counted average, IMO
ST
j
Menu Softkey
EBST
k
Display Softkey
BST
l
Red LED - Reading outside limit/ IMO Fail
ST
m
Batch Name (when in batching)
T
Date & Time (when not in batching)
ST
n
User Selectable Statistics - 4 rows
BST
o
Reading Value
EBST
p
Calibration Softkey
EBST
q
Batch / Data Softkey
BST
r
Bar Graph - highest, lowest & average reading
BST
s
Lower Limit On
ST
t
Measurement Mode - Standard, Auto Repeat, Scan
T
u
Softkeys
EBST
v
Run Chart - last 20 readings
ST
w
Upper & Lower Limits On
ST
For a complete list of icons, see “Gauge Icons” on page 66 - 68
www.elcometer.com
10
R
en
456 Dry Film Thickness Gauge
