20 PROBE TECHNICAL SPECIFICATIONS (EBST)
Available in a number of designs and scale ranges, all probes are supplied with an
Elcometer test certificate and a set of calibration foils appropriate to the scale range.
Ferrous probes measure non magnetic coatings on ferro-magnetic substrates. Non-
ferrous probes measure non conductive coatings on non-ferrous metal substrates. Dual
FNF probes measure both ferrous and non-ferrous applications with automatic substrate
detection.
Range
0 - 1500µm (0 - 60mils)
Resolution 0.1µm: 0 - 100µm; 1µm: 100 - 1500µm
(0.01mil: 0 - 5mils; 0.1mil: 5 - 60mils)
Accuracy
±1-3% or ±2.5µm (±1-3% or ±0.1mil)
Probe Design
Minimum Convex
Surface Diameter
Minimum Concave
Surface Radius
Minimum
Headroom
Minimum
Sample Diameter
Straight
Ferrous 4mm (0.16") 25mm (0.98") 85mm (3.35")
4mm (0.16")
Ferrous Sealed
4mm (0.16") 25mm (0.98") 85mm (3.35") 4mm (0.16")
Non-Ferrous 10mm (0.39") 10mm (0.39") 85mm (3.35") 4mm (0.16")
Dual FNF
F Mode: 4mm (0.16")
N Mode: 26mm (1.02")
12.5mm (0.49") 88mm (3.46")
F Mode: 4mm (0.16")
N Mode: 6mm (0.24")
Right Angle
Ferrous 4mm (0.16") 25mm (0.98") 28mm (1.10") 4mm (0.16")
Non-Ferrous 10mm (0.39") 14mm (0.55") 28mm (1.10") 4mm (0.16")
Dual FNF
F Mode: 4mm (0.16")
N Mode: 26mm (1.02")
12.5mm (0.49") 38mm (1.50")
F Mode: 4mm (0.16")
N Mode: 6mm (0.24")
Anodiser Non-Ferrous 10mm (1.38") 14mm (0.55") 100mm (3.94") 4mm (0.16")
PINIP
Ferrous 4mm (0.16") 60mm (2.36") 170mm (6.69") 4mm (0.16")
Non-Ferrous 10mm (0.39") 50mm (1.97") 180mm (7.09") 4mm (0.16")
Dual FNF
F Mode: 4mm (0.16")
N Mode: 26mm (1.02")
65mm (2.56") 180mm (7.09")
F Mode: 4mm (0.16")
N Mode: 6mm (0.24")
Minimum Substrate Thickness Ferrous:
Non-Ferrous:
0.3mm (12mils)
0.1mm (4mils)
Maximum Operating
Temperature
(limited duty cycle)
Ferrous:
Non-Ferrous:
PINIP:
PINIP
(High Temp):
150°C (300°F)
80°C (176°F)
80°C (176°F)
250°C (480°F)
Storage Temperature
-10 to 60°C (14 to 140°F)
SCALE 1
* Whichever is the greater
en
R
www.elcometer.com 76
456 Dry Film Thickness Gauge
77 of 89For more information / 1300 287 935
mail@burwell.com.au / www.burwell.com.au

Elcometer 456 Model E Specifications

General

Brand	Elcometer
Model	456 Model E
Category	Measuring Instruments
Language	English
