Probe Design
Minimum Convex
Surface Diameter
Minimum Concave
Surface Radius
Minimum
Headroom
Minimum
Sample Diameter
Mini M5
Ferrous 3mm (0.12") 6.5mm (0.26")
Headroom: 16mm (0.63")
Width: 7mm (0.28")
4mm (0.16")
Ferrous Sealed
3mm (0.12") 6.5mm (0.26")
Headroom: 16mm (0.63")
Width: 7mm (0.28")
4mm (0.16")
Non-Ferrous 10mm (0.39") 8.5mm (0.33")
Headroom: 16mm (0.63")
Width: 7mm (0.28")
4mm (0.16")
SCALE 2
Resolution 1µm: 0 - 1mm; 10µm: 1 - 5mm
(0.1mil: 0 - 50mils; 1mil: 5 - 200mils)
Accuracy ±1-3% or ±20µm (±1-3% or ±1.0mil)
For higher resolution and accuracy on thin coatings Scale 2 ferrous probes can be switched to the Scale 1 mode
measurement performance
Probe Design
Minimum Convex
Surface Diameter
Minimum Concave
Surface Radius
Minimum
Headroom
Minimum
Sample Diameter
Straight
Ferrous 4mm (0.16") 25mm (0.98") 89mm (3.50")
8mm (0.32")
Non-Ferrous 100mm (3.97") 150mm (5.90") 88mm (3.46")
14mm (0.55")
Right Angle Ferrous 4mm (0.16") 25mm (0.98") 32mm (1.26") 8mm (0.32")
Armoured Ferrous 4mm (0.16") 25mm (0.98") 138mm (5.43") 8mm (0.32")
Telescopic Ferrous 4mm (0.16") 25mm (0.98") 36mm (1.42") 8mm (0.32")
Soft Coating Ferrous Flat Surface Flat Surface 89mm (3.50") 8mm (0.32")
Waterproof Ferrous 4mm (0.16") 40mm (1.98") 138mm (5.43") 8mm (0.32")
PINIP
Ferrous 4mm (0.16") 60mm (2.36") 174mm (6.85") 8mm (0.32")
Non-Ferrous 100mm (3.97") 150mm (5.90") 185mm (7.28") 14mm (0.55")
SCALE 3
Resolution 1µm: 0 - 2mm; 10µm: 2 - 13mm
(0.1mil: 0 - 100mils; 1mil: 100 - 500mils)
±1-3% or ±50µm (±1-3% or ±2.0mils)
Probe Design
Minimum Convex
Surface Diameter
Minimum Concave
Surface Radius
Minimum
Headroom
Minimum
Sample Diameter
Straight Ferrous 15mm (0.59") 40mm (1.57") 102mm (4.02")
14mm (0.55")
PINIP Ferrous 15mm (0.59") 45mm (1.77") 184mm (7.24") 14mm (0.55")
* Whichever is the greater
