Elcometer 456 Model E - Page 79

SCALE 0.5
Range 0 - 500µm (0 - 20mils)
Resolution
0.1µm: 0 - 100µm; 10µm: 100 - 500µm
(0.01mil: 0 - 5mils; 0.1mil: 5 - 20mils)
Accuracy
±1-3% or ±2.5µm (±1-3% or ±0.1mil)
Probe Design
Minimum Convex
Surface Diameter
Minimum Concave
Surface Radius
Minimum
Headroom
Minimum
Sample Diameter
Mini-M3
45mm (1.77")
Ferrous 1.9mm (0.07") 6.5mm (0.26") 6mm (0.24") 3mm (0.12")
Non-Ferrous 6mm (0.24") 8.5mm (0.33") 6mm (0.24")
4mm (0.16")
Mini-M3-90°
45mm (1.77")
Ferrous 1.9mm (0.07") 6.5mm (0.26")
Headroom: 16mm (0.63")
Width: 7mm (0.28")
3mm (0.12")
Non-Ferrous 6mm (0.24") 8.5mm (0.33")
Headroom: 16mm (0.63")
Width: 7mm (0.28")
4mm (0.16")
Non-Ferrous
Graphite
6mm (0.24") 8.5mm (0.33")
Headroom: 16mm (0.63")
Width: 7mm (0.28")
4mm (0.16")
Mini-M3-45°
45mm (1.77")
Ferrous 1.9mm (0.07") 6.5mm (0.26")
Headroom: 18mm (0.71")
Width: 7mm (0.28")
3mm (0.12")
Mini-M3
150mm (5.90")
Ferrous 1.9mm (0.07") 6.5mm (0.26") 6mm (0.24")
3mm (0.12")
Non-Ferrous 6mm (0.24") 8.5mm (0.33") 6mm (0.24")
4mm (0.16")
Mini-M3-90°
150mm (5.90")
Ferrous 1.9mm (0.07") 6.5mm (0.26")
Headroom: 16mm (0.63")
Width: 7mm (0.28")
3mm (0.12")
Non-Ferrous 6mm (0.24") 8.5mm (0.33")
Headroom: 16mm (0.63")
Width: 7mm (0.28")
4mm (0.16")
Non-Ferrous
Graphite
6mm (0.24") 8.5mm (0.33")
Headroom: 16mm (0.63")
Width: 7mm (0.28")
4mm (0.16")
Mini-M3-90°
300mm (11.80")
Ferrous 1.9mm (0.07") 6.5mm (0.26")
Headroom: 16mm (0.63")
Width: 7mm (0.28")
3mm (0.12")
Mini-M3-45°
300mm (11.80")
Ferrous 1.9mm (0.07") 6.5mm (0.26")
Headroom: 18mm (0.71")
Width: 7mm (0.28")
3mm (0.12")
SCALE 6
Range Ferrous: 0 - 25mm (0 - 980mils)
Non-Ferrous: 0 - 30mm (0 - 1200mils)
Resolution
10µm: 0 - 2mm; 100µm: 2 - 30mm
(1mil: 0 - 100mils; 10mil: 100 - 1200mils)
Accuracy
±1-3% or ±100µm (±1-3% or ±4.0mils)
Probe Design
Minimum Convex
Surface Diameter
Minimum Concave
Surface Radius
Minimum
Headroom
Minimum
Sample Diameter
Straight
Ferrous 35mm (1.40") 170mm (6.70") 150mm (5.90")
51 x 51mm²
(2 x 2 sq. inch)
Non-Ferrous Flat Surface Flat Surface 160mm (6.30")
58mm (2.30")
Armoured
Ferrous 35mm (1.40") 170mm (6.70") 190mm (7.48")
51 x 51mm²
(2 x 2 sq. inch)
Non-Ferrous Flat Surface Flat Surface 200mm (7.87") 58mm (2.30")
en
R
* Whichever is the greater
www.elcometer.com 78
456 Dry Film Thickness Gauge
