Elcometer 456 Model E - Page 80

ULTRA / SCAN PROBES
The Elcometer 456 Ultra/Scan Probes have been specifically designed for use with the
Scan and Auto Repeat Modes on Elcometer 456 Model T separate gauges - see
Measurement Modes on page 25.
They are supplied with a highly durable ‘snap on’, user replaceable, probe cap - allowing
users to take individual readings or rapidly scan large surface areas without damaging
the probe or the coating.
They can also be used in Standard Mode - with or without the probe end cap fitted - when
connected to any Elcometer 456 separate gauge.
The cap must be fitted when used in Scan or Auto Repeat Mode. Use in these modes
without the cap will invalidate the probe warranty.
SCALE 1
Probe End Cap Fitted Without Probe End Cap
Range
100 - 1000µm (4 - 40mils)
0 - 1500µm (0 - 60mils)
Resolution
1µm (0.1mil)
1µm (0.1mil)
Accuracy
‡
±3% or ±2.5µm (±0.1mil)
‡
±1-3% or ±2.5µm (±0.1mil)
Probe End Cap Fitted Without Probe End Cap
Probe Design
Minimum
Headroom
Minimum
Sample Diameter
Minimum
Headroom
Minimum
Sample Diameter
Ultra/Scan Ferrous 86mm (3.38") 15mm (0.59") 85mm (3.35") 4mm (0.16")
Ultra/Scan Dual FNF 89mm (3.50") 15mm (0.59") 88mm (3.46")
F Mode: 4mm (0.16")
N Mode: 6mm (0.24")
‡
Whichever is the greater. When calibrated using a sample of the uncoated base.
en
R
www.elcometer.com
79
SCALE 0.5 (continued)
Probe Design
Minimum Convex
Surface Diameter
Minimum Concave
Surface Radius
Minimum
Headroom
Minimum
Sample Diameter
Mini-M3-90°
400mm (15.70")
Non-Ferrous 6mm (0.24") 8.5mm (0.33")
Headroom: 16mm (0.63")
Width: 7mm (0.28")
4mm (0.16")
Non-Ferrous
Graphite
6mm (0.24") 8.5mm (0.33")
Headroom: 16mm (0.63")
Width: 7mm (0.28")
4mm (0.16")
SCALE 2
Probe End Cap Fitted Without Probe End Cap
Range
0.1 - 4.5mm (4 - 180mils)
0 - 5mm (0 - 200mils)
Resolution
1µm: 0 - 1mm; 10µm: 1 -5mm
(0.1mil: 0 - 50mils; 1mil: 50 - 200mils)
1µm: 0 - 1mm; 10µm: 1 -5mm
(0.1mil: 0 - 50mils; 1mil: 50 - 200mils)
Accuracy
‡
±1-3% or ±0.02mm (±1mil)
‡
±1-3% or ±0.02mm (±1mil)
Probe End Cap Fitted Without Probe End Cap
Probe Design
Minimum
Headroom
Minimum
Sample Diameter
Minimum
Headroom
Minimum
Sample Diameter
Ultra/Scan Ferrous 90mm (3.54") 15mm (0.59") 89mm (3.50") 4mm (0.16")
