Elcometer 456 Model E - Elcometer 456 Model B Menu Structure

17 GAUGE MENU STRUCTURES CONTINUED (EBST)
Elcometer 456 Model B
Display
Clear Statistics Readings Only Readings & Selected Stats Readings & Bar Graph
Statistics
†
Probe
Auto FNF Ferrous F Non Ferrous N Probe Switch On
†
Probe
Ferrous F1 Ferrous F2
○ ○ ○ ○ ○ ○
Setup
Units Language Beep Volume Screen Settings Probe Gauge Auto Off Calibration Lock
Screen Settings
Screen Brightness Screen Timeout Auto Display Rotation Opening Screen
About
Gauge Information Probe Information Contact Legal
Cal Method
Zero Smooth Rough / 2 Point
○ ○ ○
○ ○ ○ ○ ○ ○ ○
Menu
Delete Last Reading Setup About Reset Emergency Light
Calibration
Calibrate Cal Method Factory Calibration Calibration Lock
○
Data
Last Five Readings
50.5 µm 52.3 µm 51.0 µm 51.8 µm
51.5 µm
Escape Delete Ok
○ ○ ○
○
○ ○
Select Statistics
Number of Readings
Mean Lowest Reading Highest Reading Standard Deviation Coefficient of Variation Elcometer Index Value
Calibration Lock
Enable PIN
Units
µm mm mils inch
○ ○ ○ ○
Legal
Patents Legal Notices Regulatory
Statistics
Clear Statistics View Selected View All Select Statistics Counted Average
†
Menu displayed is dependent on
the probe connected
en
R
www.elcometer.com 72
Regulatory
xxxxx
456 Dry Film Thickness Gauge
